TSC MH241 Series High Performance Industrial Label Printers

MH241 Series High-Performance Industrial Label Printers from TSC

The TSC MH241 Series high-performance industrial label printers reliably and quickly create up to 104 mm wide 1D/2D labels for production, transportation & logistics or for tracking products, even for healthcare.

They use either Thermal Transfer or Direct Thermal printing and achieve a maximum print speed of up to 356 mm/sec. at 203 dpi.

Depending on the requirements, you have your choice of two different variants: the Advanced (MH241T) and Premium (MH241P) models have a 4.3" colour touch display.

Both model variants of the MH241 Series high-performance industrial label printers are equipped with robust aluminium injection-moulded housing, including a metal cover and large viewing window, 6 operating keys, a 32-bit RISC CPU, 256 MB SDRAM and 512 MB flash.

They also feature a self-checking TPH maintenance mechanism and various sensors - for example, for label gaps, black mark and end of film and material (MH241T/MH241P).

The broad range of interfaces includes high-speed USB 2.0, a USB host, RS-232 and Ethernet. GPIO, Bluetooth MFi 5.0 and a Bluetooth 4.2 and Wi-Fi 802.11ac combination module are also optionally available.

The MH241 Series high-performance industrial label printers is TSC's mainstream industrial barcode label printer built upon the legacy of the MH240 Series. It brings new features to those looking for solutions to address evolving business challenges from growing production line demands to increasing operational complexities.

•  Sophisticated TSC Sense Care

The TSC TPH Care Mechanism offers an advanced level of auto-detection ensuring real-time printhead health status, to monitor and prevent down. In addition, the MH241/MH261 series support various media with pre-printed black mark on top or bottom sides by user’s selection in panel menu.

•  Dynamic Remote Printer Management

SOTI Connect and TSC Console provide enterprise remote printer management on multiple tasks to reduce maintenance costs and avoid downtime of business-critical devices.

•  Multi-Connectivity

The MH241/MH261 series offers GPIO to support common applicators and emulations along with an optional 802.11 a/b/g/n/ac Wi-Fi with Bluetooth 4.2 combo module.

•  Highly Adaptable to Various Media

MH241 and MH261 printers can adapt to various media lengths and widths. With accurate printing positioning, the MH241 and MH241T are capable of peeling off minimum 0.5-inch labels in length. The MH261T supports media width up to 6.8-inches, and the MH261 supports up to 4.5-inches. Additionally, the mechanism for fine adjustment to avoid ribbon wrinkles and ensures label print quality.

•  Brilliant User Experience

The MH241T and MH241P can easily adjust the media near-end sensor to detect the media and remind users to change the media roll on colour GUI display (Media near end). The MH241/MH261 series allows users to easily replace printhead and platen roller without the need for specific tools.

Key Features

• Max. print speed: 356 mm/sec. at 203 dpi
• Different variants: Advanced (MH241T), Premium (MH241P)
• Industrial thermal transfer printers for high-quality label printing
• 3.5" colour display or 4.3" colour touch display (MH241T/MH241P)
• USB 2.0, USB host, RS-232 and Ethernet; optional combination module and Bluetooth MFi 5.0
