Unitech PA760 Enterprise Level Rugged Smartphone with Barcode Scanning
Offering the latest OS of Android 9, a robust processor, and a rugged scanner, the PA760 also comes with the Google GMS license, makes your toughest work days easier. It is ideal for a variety of applications including inventory control in warehouse, inbound and outbound management in the retail industry, parking management and facilities inspection in field service, and flight ticket checking and mobile POS system in transportations
Physical Characteristics
| Dimensions | 163 mm x 75 mm x 17.4 mm |
| Weight | 300g (with standard battery) |
| Display | Gorilla Glass 3 with 5-point Capacitive Touch Panel 5.45” Color LCD 1440x720 High Resolution Display 500 cd/m2 Brightness |
| Buttons | Side SCAN button x 2 (Left / Right), Power button, User-defined function button (programmable key), Volume switch button (+ / -), ON / OFF button. |
| Scanner | 1D and N6603 2D Support + NFC |
| Power | Main Battery: Standard 4000mAh / battery with cover in one Operation Time: >10 hours Charging Time <3 hours (supports QC4.0 quick charge) |
Performance Characteristics
| OS | Android 9.0 with GMS Certification |
| Memory | 4GB RAM 64GB ROM |
| CPU | Qualcomm 660 2.2 Ghz Octa-Core |
| Card Slot | Micro SD/SDHC/SDXC (up to 128GB) + Dual Nano-SIM |
| SIM | Nano-SIM X 2 |
Communication
| WWAN | LTE FDD: Band 1(2100), Band 2(1900), Band 3(1800), Band 4(1700), Band 5(850), Band 7(2600), Band 8(900), Band 17(700bc), Band 20(800), Band 28(700) TDD: Band 38(2600), Band 39(1900), Band 41(2500) |
| WLAN | IEEE 802.11 a/b/g/n/ac/d/h/i/k/r/v, support fast roaming, MIMO(2x2) |
| Bluetooth® | Bluetooth® 5 supported |
| Interface | USB 2.0 with Pogo Pin USB OTG Type C Connector for PC/USB drive POGO PIN connector for Cradle |
| GPS & Additional Communication | GPS/GLONASS/Gallileo/Beidou Support NFC, fingerprint (optional) |
Certifications & Warranty
| Certifications | CE, RoHS |
| Warranty | Terminal: 1 year Battery: 3 months |
User Environment
| Operating Temperature | -20°C to 50°C |
| Storage Temperature | -30°C to 60°C |
| Relative Humidity | 5% ~ 95% (Non-Condensing) |
| IP Rating & Drop Specification | IP67 1.5 meter without bumper 1.8 meter with bumper |
Accessories
| Available | Hand Strap 4-Slot Ethernet cradle Adapter (US, EU, UK plugs) 4-Slot Terminal Charging cradle USB type C cable 4-Slot battery charger Tray Ejector tool Gun Grip for trigger only Bumper (by model selection) Gun Grip for UHF reader 9H glass screen protector Stylus & Coiled strap Terminal & Charging cradle Ethernet cradle with USB host Gun Grip for Long range 2D Barcode reader |
Key Features
- The First 5.45" (18:9) inch Android 9.0 rugged mobile computer with split-screen function
- Advanced 64-bit Qualcomm Snapdragon 660 octa-core CPU
- Google Certification : Android Compatibility Test Suite (CTS ) / Google Mobile Service (GMS)
- 3.4V 4000 mAh Li-ION battery with optional 3.8V 6000 mAh
- 1.5M drop-resistant housing (1.8M drop-resistance with bumper)
- IP67 heavy-duty protection against water and dus
- Leading 4G dual SIM card enterprise handheld computer
